• Paint, solid
• Body, standard
• Bumpers, front and rear, painted Black, includes step-pad (Not available with (ZR7) Chrome Appearance Package.)
• Grille, Black composite, with single rectangular halogen headlamps (Not available with (ZR7) Chrome Appearance Package.)
• Headlamps, single rectangular halogen (Not available with (ZR7) Chrome Appearance Package.)
• Daytime running lamps
• Mirrors, outside rearview, manual folding, Black (If the van is an extended Model (*G**7**), or if the van has no rear windows, then the van will get a flat right side mirror. All other vans will have a convex right side mirror.)
• Glass, Solar-Ray light tinted, all windows
• License plate kit, front
• Wipers, intermittent, front wet-arm with pulse washers
• Door, swing-out passenger side, 60/40 split

• Seats, driver and passenger high-back reclining buckets, adjustable, with head restraints and vinyl or cloth trim
• Seats, front vinyl reclining buckets, includes head restraints (Requires (**W) Interior Trim.)
• Console, base, includes open storage bin
• Floor covering, Black rubberized vinyl full length floor covering (Not available with (YF2) Ambulance Package.)
• Steering wheel, steel sleeve column, includes theft-deterrent locking feature, Black
• Oil life monitor
• Warning tones, headlamp on, key-in-ignition
• Tow/haul mode selector, IP mounted
• Theft-deterrent system, PASSlock
• Air conditioning, front manual
• Defogger, side window
• Sound system, radio provisions only, includes alarm warning chimes, radio wiring harness, radio antenna and front door speakers (2) (Not available with (PCH) Hotel Shuttle Package.)
• Mirror, inside rearview, manual day/night
• Headliner, cloth, over driver and passenger
• Visors, padded, driver and passenger side
• Assist handle, front passenger
• Lighting, 2 dome lamps, includes defeat switch and door handle-activated switches

• Brakes, 4-wheel antilock, 4-wheel disc
• Air bags, frontal, driver and right front passenger (Includes passenger side deactivation switch on Models with GVWR, 8600 lbs. (3901 kg) and above. Not available with (ZX1) Seat, driver only high-back reclining bucket or (AJ3) Air bag, frontal, driver side only. Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owners Manual for more safety information.)
• Door beams, steel-side
• Daytime running lamps

ENGINE, VORTEC 4300 V6 MFI

• (195 HP [145.4 kW] @ 4600 rpm
• 260 lb.-ft. [351.0 N-m] @ 2800 rpm) (STD)

• ABS (4-Wheel)
• Automatic
• Dual Air Bags
• Tilt Wheel
• Air Conditioning
• Steel Wheels
• RWD
• V6 4.3 Liter
• Cruise Control
• Power Windows
• AM/FM Stereo
• Power Door Locks
• Power Steering

• Vehicle
• Rear Door Type: Dual Swing-out
• Mileage
• EPA Fuel Economy Est - City (MPG): 15
• EPA Fuel Economy Est - Hwy (MPG): 20
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 105
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 11.72
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 4000
• Curb Weight - Front (lbs): 2643
• Curb Weight - Rear (lbs): 2077
• Gross Vehicle Weight Rating Cap (lbs): 7200
• Gross Combined Wt Rating (lbs): 9500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 4000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 400
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 4300
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 645
• Suspension
• Suspension Type - Front: Independent Coil
• Suspension Type - Rear: Hypoid Multi-Leaf
• Spring Capacity - Front (lbs): 3600
• Spring Capacity - Rear (lbs): 4000
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3600
• Axle Capacity - Rear (lbs): 4000
• Axle Ratio (:1) - Rear: 3.42
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): 1.30
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12 x 1.1
• Rear Brake Rotor Diam x Thickness (in): 13 x 1.2
• Tires
• Front Tire Order Code: XEN
• Rear Tire Order Code: YEN
• Spare Tire Order Code: ZEN
• Front Tire Size: P235/75R16EL
• Rear Tire Size: P235/75R16EL
• Spare Tire Size: P235/75R16EL
• Front Tire Capacity (lbs): 1903
• Rear Tire Capacity (lbs): 2004
• Spare Tire Capacity (lbs): -TBD-
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x - TBD -
• Rear Wheel Size (in): 16 x - TBD -
• Spare Wheel Size (in): 16 x - TBD -
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr-Assisted
• Steering Ratio (:1), On Center: 17.2
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 43.4
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 31
• Fuel Tank Location: LH Midship Inboard
• Doors
• Side Door Type: Swing-out
• Exterior Dimensions
• Wheelbase (in): 135
• Length, Overall w/rear bumper (in): 224.1
• Width, Max w/o mirrors (in): 79.4
• Height, Overall (in): 81.6
• Overhang, Front (in): - TBD -
• Overhang, Rear w/bumper (in): - TBD -
• Ground to Top of Load Floor (in): 27.7
• Ground Clearance, Front (in): 8.6
• Ground Clearance, Rear (in): 7.6
• Rear Door Opening Height (in): 49.4
• Rear Door Opening Width (in): 57.0
• Side Door Opening Height (in): 47.9
• Side Door Opening Width (in): 44.1
• Step Up Height - Front (in): 20.1
• Step Up Height - Side (in): 20.9
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Console (in): 153.6
• Cargo Area Length @ Floor to Seat 1 (in): 127.8
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 52.7
• Cargo Box (Area) Height (in): 51.9
• Cargo Volume (ft³): 225.1
• Interior Dimensions
• Passenger Capacity: 2
• Front Head Room (in): 40.2
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 68.8
• Front Hip Room (in): 65.5
• Summary
• Vehicle Name: Chevrolet Express Cargo Van
• Body Style: 1500 Cargo Van 135" WB
• Body Code: ZW9
