• Luggage rack, roof-mounted, chrome accent
• Cladding, doors only, body-color protective
• Bumper, front, body-color
• Bumper, rear, body-color step, includes pad
• Door handles, chrome
• Assist handle, cargo bed ingress
• Assist steps, color-keyed, with chrome accents, mounted between front and rear wheels
• Cargo cover, rear, rigid, 3-piece composite, stowable onboard
• Utility Enhancement System (UES), includes Midgate panel, removable/stowable rear window, removable/stowable 3-piece rigid cargo cover, integrated top box storage, lockable, lit storage areas and black rubber cargo bed mat
• Headlamps, High-Intensity Discharge, includes flash-to-pass feature and Twilight Sentinel automatic lamp control
• Fog lamps, front, rectangular, halogen, incorporated into the front fascia
• Daytime running lamps, includes automatic exterior lamp control
• Glass, Solar-Ray light tinted, except rear passenger doors which are deep tinted
• Mirrors, outside rearview, power folding, power, heated, color-keyed, driver side electrochromic (light-sensitive auto dimming), turn signal in glass, with ground illumination, programmable to provide curb view when in reverse
• Rear Park Assist, Ultrasonic (URPA), includes instrument panel-mounted shutoff switch, rearview LED light bar and audible chime warning
• Wipers, intermittent, front wet-arm with pulse washers

• Seats, front leather seating surfaces, power reclining full-feature buckets, articulating head restraints, driver and front passenger 14-position power adjusters, fold-down inboard armrests, independent heated seat cushion and seatback for driver and passenger (3 settings), power lumbar and side bolsters and 2-position memory driver seat
• Seats, rear 60/40 split-bench, folding, leather seating surfaces, 3-passenger with folding center armrest with storage
• Nuance leather seating surfaces
• Console, floor, includes damped-door storage covers, large storage bin, analog clock, dual cupholders and rear seat audio controls
• Console, overhead deluxe, includes reading lights, (UG1) Universal transmitter and storage
• Floor covering, color-keyed carpeting
• Steering wheel, color-keyed, wood and leather-wrapped rim
• Steering wheel mounted audio and Driver Information Center controls
• Driver Information Center, includes programmable personalization features such as door locking and unlocking, a trip computer that contains two trip odometers and individual tire pressure read outs, fuel information such as range, average mpg, gallons used and oil life, and a message center that records up to 37 system warning messages such as low fuel, door ajar, security, seat belt reminder, low coolant and oil pressure low
• Tire pressure monitor
• Windows, power, includes driver and front passenger express-down and lockout features
• Door locks, power programmable, includes lockout protection
• Tow/haul mode selector, button located at end of shift lever
• Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
• Theft-deterrent system, PASSlock
• Keyless entry, remote, includes 2 transmitters, panic button and content theft alarm
• OnStar, 1-year Directions & Connections Service, includes Driving Directions, Information/Convenience Services, RideAssist, Automatic Notification of Air Bag Deployment, Stolen-Vehicle Tracking, Emergency Services, Roadside Assistance, Remote Door Unlock, Remote Horn and Lights, GM Goodwrench Remote Diagnostics, AccidentAssist and Online Concierge. Drivers can also obtain the available voice-activated, hands-free Personal Calling service and Virtual Advisor that provides location-based traffic and weather reports and other personalized information. (Visit www.onstar.com for system information and details.)
• Universal Transmitter, Homelink, includes garage door opener, 3-channel programmable
• Climate control, dual-zone, automatic, includes individual climate settings for driver and right front passenger
• Defogger, rear-window, electric
• Sound system, ETR AM/FM stereo with CD and cassette player, includes AudioPilot noise compensation technology, seek-and-scan, digital clock, and Radio Data System (RDS)
• Sound system, 6-disc CD changer, in-dash
• Sound system feature, Bose luxury speaker system, enhanced performance amplification, Audio Pilot noise reduction feature, 7 speakers including sub woofer
• Sound system feature, rear audio controls, includes dual headphone jacks (headphones not included), power outlet and controls for volume, station selection and media
• Sound system feature, XM Satellite Radio, features 67 channels of 100% commercial-free music included in its over 150 channels of the best in music, news, sports, talk, comedy, XM Instant Traffic and Weather, and more. Digital quality sound with coast-to-coast signal coverage. Three trial months - no obligation. (Subscription fees apply. Available only in the 48 contiguous U.S.)
• Cupholders, dual, front, rear and tailgate
• Mirror, inside rearview, electrochromic (light-sensitive auto dimming), 8-point compass and outside temperature indicator
• Assist handle, front passenger, color-keyed
• Lighting, interior courtesy, theater dimming
• Midgate panel, foldable door between cargo bed and cab, removable and stowable rear window
• Pedals, power adjustable, with memory

• Brakes, 4-wheel antilock, 4-wheel disc, Hydroboost
• Air bags, frontal and side-impact, driver and right front passenger, includes Dynamic Passenger Sensing System and frontal dual-level air bags (Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information.)
• Safety belts, 3-point, lap and shoulder, all seating positions
• Traction control system, electronic, all-speed
• Daytime running lamps, includes automatic exterior lamp control

ENGINE, VORTEC HIGH-OUTPUT 6000 V8 SFI

• (345 HP [257.0 kW] @ 5200 rpm
• 380 lb.-ft. [513.0 N-m] @ 4000 rpm) (STD)

• Cruise Control
• Side Air Bags
• Alloy Wheels
• AWD
• Roof Rack
• Traction Control
• AM/FM Stereo
• Dual Air Bags
• CD/MP3 (Multi Disc)
• OnStar
• Towing Pkg
• ABS (4-Wheel)
• Power Steering
• Automatic
• Air Conditioning
• Power Door Locks
• Cassette
• Running Boards
• Power Windows
• Parking Sensors
• V8 6.0 Liter
• Premium Sound
• Leather
• Dual Power Seats
• Tilt Wheel

• Mileage
• EPA Fuel Economy Est - City (MPG): 13
• EPA Fuel Economy Est - Hwy (MPG): 17
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 145
• Cooling System
• Total Cooling System Capacity (qts): 13.4
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3800
• Gross Axle Wt Rating - Rear (lbs): 4000
• Curb Weight - Front (lbs): 3233
• Curb Weight - Rear (lbs): 2646
• Gross Vehicle Weight Rating Cap (lbs): 7000
• Gross Combined Wt Rating (lbs): 14000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 600
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7300
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 730
• Suspension
• Suspension Type - Front: Indep Torsion Bar
• Suspension Type - Rear: 5-Link coil spring
• Spring Capacity - Front (lbs): 3800
• Spring Capacity - Rear (lbs): 4000
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-floating
• Axle Capacity - Front (lbs): 3800
• Axle Capacity - Rear (lbs): 4000
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 46
• Shock Absorber Diameter - Rear (mm): 46
• Stabilizer Bar Diameter - Front (in): 1.26
• Stabilizer Bar Diameter - Rear (in): 1.14
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12 x 1.14
• Rear Brake Rotor Diam x Thickness (in): 13 x 1.18
• Tires
• Front Tire Order Code: QAN
• Rear Tire Order Code: QAN
• Front Tire Size: P265/70R17
• Rear Tire Size: P265/70R17
• Spare Tire Size: - TBD -
• Front Tire Capacity (lbs): 2134
• Rear Tire Capacity (lbs): 2134
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 7.5
• Rear Wheel Size (in): 17 x 7.5
• Spare Wheel Size (in): 16 x - TBD -
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 14
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 43.1
• Turning Diameter - Wall to Wall (ft): 46
• Frame
• Frame Type: Ladder-type
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 31
• Exterior Dimensions
• Wheelbase (in): 130.0
• Length, Overall w/o rear bumper (in): 221.4
• Width, Max w/o mirrors (in): 79.5
• Height, Overall (in): 75.6
• Overhang, Front (in): - TBD -
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): - TBD -
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 31.0
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 10.6
• Ground Clearance, Rear (in): 10.6
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 63.0 Min, 97.6 Max
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 50.0
• Cargo Box Width @ Wheelhousings (in): - TBD -
• Cargo Box (Area) Height (in): - TBD -
• Tailgate Width (in): - TBD -
• Cargo Volume (ft³): 41.0 Min, 95.0 Max
• Ext'd Cab Cargo Volume (ft³): 53.9
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 40.7
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 62.0
• Second Head Room (in): 38.6
• Second Leg Room (in): 38.9
• Second Shoulder Room (in): 65.2
• Second Hip Room (in): 62.0
• Summary
• Vehicle Name: Cadillac Escalade EXT
• Body Style: 5 Door Crew Cab
